Dawei medical

ICU CCU Ambulances Portable Vital Signs 6-Parameter Patient Monitor HM10 | DAWEI

ICU CCU Ambulances Portable Vital Signs 6-Parameter Patient Monitor HM10 | DAWEI

Regular price $799.00 USD
Regular price $989.00 USD Sale price $799.00 USD
Sale Sold out
Model

ICU CCU Portable Vital Signs 6-Parameter Medical Monitor HM10

 Features and benifits
Monitoring scope HR, ECG, SPO2, NIBP, RESP, TEMP, CO2 (optional).
  1. 1024*768 color LCD display, full viewing angle display, 10-level brightness adjustment;
  2. The vertical button layout on the right side satisfies the quick operation of various scenarios;
  3. 30-second blood pressure measurement, performance, function, all-around;
  4. ECG 12-coreanti-interference socket design;
  5. There are three filtering modes of monitoring, diagnosis and surgery, to satisfy various scenarios;
  6. There are more than three ways to enter the alarm limit setting, and there is no need to operate too much for newly received patients;
  7. Support fast import/export of USB configuration to meet the needs of different departments;
  8. Large storage capacity: it can meet the data storage requirements of continuous patient monitoring for at least 960 hours;
  9. With blood pressure STAT measurement mode, it will automatically exit after 5 minutes of continuous measurement;
  10. With automatic blood pressure measurement interval time adjustment above level 10, to meet the needs of different patients for monitoring;
  11. Support Multi-language, Chinese, English, Italian, Spanish, Turkish, Portuguese, Polish, Germany, Russian; convenient operation of patient information entry\delete\save;
  12. 20 kinds of arrhythmia event alarms, support ST segment analysis function;
  13. Trigger the printing function, record every abnormality in time; improve the communication efficiency between nurses and doctors (optional);
  14. Double overpressure protection of blood pressure software and hardware to ensure patient safety; six groups of data are displayed on the same screen, and trend analysis is clear at a glance;
  15. Super long alarm light, 360-degree visibility, easier to monitor patient status information;
  16. The alarm sound and the pulse rate sound are independent, the pulse rate sound continues to respond when the alarm is muted, and the alarm sound can be activated normally when the pulse rate sound is muted;
  17. The waveform display has two ways of curve and filling to meet the needs of different departments;
  18. Large-capacity built-in lithium battery, continuous working time ≥ 300 minutes;
  19. When the waveform screen is frozen, the real-time parameters are continuously displayed in the parameter area; the frozen waveform can be viewed forward and backward along the time axis.
  20. Anti-defibrillation, anti-electric knife, anti-power grid, anti-myoelectric and other interference;
  21. Low battery alarm, no data loss at critical moments;
  22. Support USB firmware upgrade outside the machine, get rid of local restrictions.

Standard Configuration:

ECG, blood oxygen, blood pressure, respiratory rate, body temperature, heart rate;

Optional Configuration:

printer, main stream/side stream ETCO2, etc.

Optional Accessories: trolley, wall bracket, etc.;

HM10 model Packing Size: 40*28*35cm, Net weight: 3KG, gross weight: 5.8KG.


WHAT'S IN THE BOX?

HM10 - 1 set including follows

  • HM10 - patient monitor main unit
  • ECG cable *1
  • Blood pressure cuff connecting tube *1
  • NIBP cuff *1
  • Blood oxygen saturation probe *1
  • Temperature probe *1
  • Disposable ECG electrodes *10 pcs
  • Power cord *1

PARAMETER PERFORMANCE INDEX

ECG:

Lead selection: three/five lead standard; up to 7 leads can be displayed on the same screen

I, II, III, AVR, AVL, AVF, V chest leads

ECG detection range: 15~350bpm

Resolution: 1bpm

Measurement accuracy: the greater of ±2% or ±2bpm

Frequency Response: 0.67Hz-40 Hz

S-T segment monitoring: -2.0mV~2.0mV

Electrode drop indication: sound, light prompt

Scanning speed: 6.25, 12.5, 25, 50mm/sec

Gain selection: ×0.125, ×0.25, ×0.5, ×1, ×2, ×4, auto

ECG calibration: 1mV+5%

Protective isolation withstands 4000V/AC/50Hz voltage;

ECG cable lead wire: 3/5 lead

Standard configuration: adult universal ECG cable

Optional configuration: ECG cable for pediatric and neonatal

Alarm: The upper and lower limits of the alarm value can be set and automatically memorized; there is an alarm review;



Blood oxygen saturation:

Display: blood oxygen value, pulse histogram, waveform, pulse value

Blood oxygen range: 0%-100% adult/child/neonatal

Resolution: 1%

Accuracy: ±3% (Undefined below 70%)

Pulse rate:

Measuring range: 30~280bpm

Pulse accuracy: ±2bpm

Alarm range: 20~300bpm, the lower limit cannot be greater than the upper limit

Sensor:

Standard configuration: adult soft finger ring

Optional configuration: soft finger ring for pediatric, neonatal strap

Alarm value: upper and lower limits can be set, automatic memory

Non-invasive blood pressure(NIBP):

 Measurement method: Oscillation method

Measurement parameters: systolic blood pressure, diastolic blood pressure, mean blood pressure

Working mode: manual, automatic, continuous measurement

Unit: mmHg/kPa optional

Measurement interval time of automatic measurement mode: 2.5~120min, ten-level adjustable

Overvoltage protection: software and hardware overvoltage protection

 Measuring range:

Item

Adult

Pediatric

Neonatal

Systolic blood pressure (mmHg)

40~255

40~200

40~135

Diastolic blood pressure (mmHg)

20~205

20~150

20~100

Average pressure (mmHg)

27~220

27~165

27~110



Cuff pressure range: 0-300 mmHg

Cuff:

Standard configuration: adult cuff

Select Configurations: Neonatal Cuff, Child Cuff

Alarm setting range:

Systolic blood pressure: 40~255mmHg, and the lower limit cannot be greater than the upper limit (adult),

         40~200mmHg, and the lower limit cannot be greater than the upper limit (pediatric),

         40~135mmHg, and the lower limit cannot be greater than the upper limit (neonatal);

Diastolic blood pressure: 10~195mmHg, and the lower limit cannot be greater than the upper limit (adult),

         10~150mmHg, and the lower limit cannot be greater than the upper limit (pediatric),

         10~110mmHg, and the lower limit cannot be greater than the upper limit (neonatal);

Average pressure: 20~215mmHg, and the lower limit cannot be greater than the upper limit (adult),

         20~165mmHg, and the lower limit cannot be greater than the upper limit (pediatric),

         20~125mmHg, and the lower limit cannot be greater than the upper limit (neonatal);

Alarm display error: not more than ±5% of the set value.



Temperature:

 Temperature measurement range: 0℃~50℃

Temperature measurement error: no more than ±0.1℃

Resolution: 0.1℃

Accuracy: ±0.2°C (including sensor error)

Probe:

Standard configuration: permanent body temperature probe

Select configuration: esophageal temperature probe, rectal temperature probe.

Alarm value: upper and lower limits can be set, automatic memory

Alarm: All monitoring parameters can be set to alarm, and it has an alarm device that emits sound and light, and can cancel the alarm



Breath measurement:

Measurement method: thoracic impedance method

Respiratory rate measurement range and accuracy

Measuring range: adult: 0~ 120rpm;

           Pediatric/Neonatal: 0~150rpm.

Measurement accuracy: 10~150 rpm ±2 rpm or ±2%, whichever is greater;

             0~9 rpm is undefined.

Respiratory rate measurement resolution

Resolution: 1 rpm

Apnea alarm delay time

Can be set to: 20s, 25s, 30s, 35s, 40s, 45s, 50s, 55s, 60s

Respiratory rate alarm limit range

Adult pediatric/neonatal alarm limit can be set as: 2~150rpm
