Hospital Clinic Health Care Center Portable 12 Channel ECG Machine ME12 | DAWEI
Hospital Clinic Health Care Center Portable 12 Channel ECG Machine ME12 | DAWEI
Couldn't load pickup availability
From US$1269 down to US$956, Enjoy 25% off
Product name: Brand new Portable 10.2-inch Touch Screen 12 Channel ECG Machine With Printer ME12
Functional features
- Support languages: CHN ENG RUS FREN GER PORTU SPAN
- 12-lead synchronous ECG acquisition;
- equipped with high speed and high sensitivity hot spot recording system, with print trace depth adjustment function;
- 10.2-inch high-definition and wide-angle color LCD screen, capacitive touch control, 12-lead display;
- six ECG record combination modes;
- single line /3 channel/(3+R) channel/(+l+V5) channel/double line 6 channel/single line 6 channel/single/double line 12 channels eight ECG display combination mode;
- accurate ECG automatic diagnosis function, with heart rate exceeding alarm function, and set whether to print the measurement and analysis report;
- full keyboard Chinese touch input (pinyin and wubi optional), can enter hospital and patient information;
- with real-time ECG waveform freezing function, it is easy to grasp the patient's important ECG waveform;
- manual, automatic, rhythm, physical examination and other operating modes;
- with RS232 communication interface, USB interface and LAN network interface;
- external large capacity USB memory, can achieve the storage, playback and printing of historical data on the computer;
- built-in large capacity any ion rechargeable battery, and a special charging circuit and perfect battery management and protection system;
- with lead off detection function, with paper shortage detection function;
- wide power supply design, suitable for 110-230, 50/60hz ac power supply.
- memory capacity can be expanded by USB flash drive.
★ can be connected to the ECG workstation, with a strong patient file management function, can store up to 500 ECG reports;
★ 12-lead automatic ECG analysis system: ECG automatic diagnosis function, automatic ECG measurement and analysis for doctors' reference;
★ high resolution thermal matrix printout; Baseline stability test to ensure a neat and beautiful ECG waveform every time;
★ Save the ECG report format as ECG, which can only be opened through the ECG report browser (free) after saved in the computer.
WHAT'S IN THE BOX?
WHAT'S IN THE BOX?
ECG Machine ME12- Group A -button type ECG cable
- Main unit *1
- 12-Lead ECG cable(button type) *1
- Disposable electrode pads *10 pcs
- Printing paper *1 roll
- Power cable *1
ECG Machine ME12- Group B -plug-in type ECG cable
- Main unit *1
- 12-Lead ECG cable(plug-in type) *1
- Suction ball (adult) *6 pcs
- Limb clip (adult) *4 pcs
- Printing paper *1 roll
- Power cable *1
ECG Machine ME12- Group C -clamp type ECG cable
- Main unit *1
- 12-Lead ECG cable(clamp type) *1
- Disposable electrode pads *10 pcs
- Printing paper *1 roll
- Power cable *1
PARAMETER PERFORMANCE INDEX
PARAMETER PERFORMANCE INDEX
Technical indicators
Common mode rejection ratio |
≥100dB |
|
The input circuit |
Float, defibrillation |
|
Input loop current |
≤0.1чA |
|
Sampling rate |
12bit/1000HZ |
|
Operating mode |
Manual/automatic |
|
The filter |
Working filter, electromechanical filter |
|
Drift filtering |
Anti-drift system |
|
The input impedance |
>50MΩ |
|
Patient leakage current |
<10чA |
|
Fuse specification |
T1.6A/ 250V Ø5×20 |
|
Recording paper specification |
Scroll/folding thermal recording paper (210mm ~ 216mm self-adaptive) |
|
Calibration voltage |
1mV±3% |
|
Polarization resistance voltage |
±500m V |
|
Time constant |
≥3.2s |
|
Frequency response |
0.05Hz ~ 165Hz |
|
Noise level |
≤15чVp-p |
|
Minimum detection signal |
≤20чV |
|
The feeding speed |
12.5 mm/s、25mm/s、 50mm/s |
|
The sensitivity |
5,10,20 (mm/mV ±5 %) |
|
record |
Twelve high resolution thermal print |
|
The battery |
14.52V/5200mAh(75.504Wh) |
|
Overall dimensions |
343mm×306mm×98mm |
Net weight: 4.25 KG |
Size of packing box |
400mm×350mm×200mm |
Gross weight: 6.2 KG |
PRODUCT FAQs & TIPS
PRODUCT FAQs & TIPS
How will I conduct this machine?
- A paper version of the Quick Operation Guide will be in the shipment
- PDF of the User Manual
- Free training
- Online support
ECG waveform interface after connecting to the workstation
What are the functions in the settings interface?
✅Click the [Settings] icon on the navigation interface, and the machine enters the setting interface.
✅ Settings include: system settings, sampling settings, analysis settings, print settings, hospital information.
How to perform a 12-lead ecg?
An ECG stands for electrocardiogram. It is a tool used to detect a wide range of heart dysrhythmias using waveforms on a monitor. It is used by healthcare providers regularly both in the hospital and by EMS.
Read more: Simple Steps for 12-lead ECG Application
How to connect lead cables?
✅The lead wires include 6 chest leads and 4 limb leads.
✅Users can distinguish the chest leads from the limb leads by the color of the lead wires and the logo on the electrode plug.
✅Connect the lead wire: Insert the lead wire plug into the cable socket (Patient) on the right side of the electrocardiograph, and tighten the knobs on both sides of the plug.

How to install Thermal Recording Paper?
The installation steps of printing paper are as follows:
1) Press the button of the paper compartment cover on the left side of the machine to pop up the paper compartment cover;
2) Take off the packaging of the new reel recording paper, put the printing paper inside the paper reel, and place it in the printing paper compartment;
3) Pull out the recording paper about 2cm, insert the printer cover horizontally and press the printer cover firmly.
Note: Thermal paper can only be printed on one side, if the thermal paper is installed backwards, the information will not be printed normally. Judgment method: After pulling out the thermal paper and closing the cover of the paper compartment, pull the thermal paper to the left, and the ECG grid should be facing up.
We provide the following seven types of power cords:
US plug, UK plug, EU plug, IT plug, SA plug, IL plug, Great SA plug
Please note the required power cord version in the order. If there is no note, the power cord version will be selected according to the country where the order is shipped.
